The Evopower LT600-LED-D is an LED lighting tower powered by the Hyundai DHY6000SE 5.2kw silenced diesel generator and is suitable for a wide range of applications including large outdoor events, sports fields, construction and work sites, workshop, farming, logistics, rural and hard to reach areas and temporary public lighting. The LT600-LED-D provides a flexible lighting solution by allowing users to easily plug into any power source including auxiliary power, portable generators or directly into the mains power supply.
The Evopower LT600-LED-D mobile lighting tower boasts high efficiency, the highly efficient LED light heads deliver a powerful 12500 lumens at only 600W (150w x 4) power consumption.
Easy to transport the LT600-LED-D lighting tower features 4 pneumatic off road tyres, with rapid one person deployment simply push the lightning tower into place apply the brake, lower the stabiliser legs and erect the mast using the single operator winch handle. Towering 5 metres in height from the ground the LT600-LED-D provides excellent illumination of large areas requiring temporary lighting.
Mains or generator powered the LT600-LED-D can be used with existing 230 volt power supply equipment, due to low power consumption the generator is also available to run other electrical equipment.
Each lighting tower can be daisy chained (connected in series) to allow up to 8 lighting towers to be powered from one 6kw generator, making for ultra low fuel consumption of less than ¼ litre per hour for each tower (assumes upto 2 litres an hour for the generator).
These lighting towers can be supplied to run from either 110v or 230v - please specify the voltage required when ordering.
COVERAGE: Luxes are used to measure the amount of light output in a given area - one lux is equal to one lumen per square meter. It enables the measurment of the total amount of visible light present and the intensity of the illumination on a surface.
20 Luxes: area is up to 2500m2
30 Luxes: area is up to 1800m2
50 Luxes: area is up to 1300m2
100 Luxes: area is up to 700m2
In The Box: LT600-LED-D Lighting Tower, DHY6000SE 5.2kW Diesel Generator, Assembly Tools & User Manual.
NOTE: Hyundai DHY6000SE 5.2kW Diesel Generator is included.(When supplied with a lighting tower, this generator has rubber feet instead of wheels).
Lighting Tower covered by Evopower 2 year warranty, Generator covered by Hyundai 1 year standard warranty.
- Low fuel consumption less than 1 litre an hour (when powered by the included 5.2kW DHY6000SE Diesel Generator). Can run on red or white diesel.
- Additional 6 bare lighting towers can be daisy chained and run from one generator.
- Multi-directional adjustable and tiltable LED floodlights.
- 4x150W LED Lights 110-230v (Please specify sockets required).
- High 12,500 lumen output light coverage from each lamp.
- Quick and easily erected by a single operator.
- 5 metre mast on steerable trolley with twin stabilizers.
- 30,000hrs lamp durability.
- Full UK spares backup to maintain your machine for years to come.
- Covered by Evopower 2 year warranty (lighting tower only)
| Field | Details |
|---|---|
| Mast raised height | 5 Metres |
| Lamp Wattage | 4x 150W LED |
| Maximum wind speed | 50 km/h Max |
| Engine model number | D420 |
| Noise level LWA | 96 dB |
| Warranty | 1 Year (Generator), 2 Years (Lighting Tower) |
| Wheel kit | Yes included |
| Cooling system | Air cooled |
| Engine HP | 10 HP HP |
| Low Oil Shutdown | Yes |
| Model Code | LT600-LED-D |
| Supplier Model Code | LT600-LED-D |
| Engine Brand | Hyundai |
| Engine type | Single cylinder 418cc |
| KVA | 6.5 kVA |
| Max Watts | 5200 W |
| Light coverage | 2500m2 (average 20 luxes) |
| Rated Watts | 4500 W |
| Phase | Single |
| Fuel | Diesel |
| Fuel tank capacity | 16 Litres |
| Sockets | 1 x 110V 16A, 1 x 110v 32A, 1 x 230V 32A |
| Starting system | Electric |
| Run Time | 16 hours |
| Noise Level @ 7m | 70 dBA |
| Frequency | 50 Hz |
| Rated Voltage | 230v / 110v |
| RPM | 3000 RPM |
| Dimensions (LxWxH) | 1200 x 880 x 1950 mm |
| Weight | 270 kg (generator & tower) |
